Plugin Development Intro

A plugin is a Python package, distributed as a .zip, that contributes one or more methods, object-centric process mining (OCPM) functions other users can run from the Ocelescope UI. This section covers writing one. For the user-facing side, what a plugin is and what it does for someone running Ocelescope, see Plugins.

Plugin Capabilities

The plugin system is built so that writing Python is most of the job; Ocelescope takes care of the rest:

• Resources you define (the OCEL artifacts your methods consume or return) automatically get a JSON-based exchange format, so users can export and re-import them without you writing any serialization code.
• Resources can ship a visualization, so they render in the frontend, as a graph, a table, a chart, and so on, out of the box.
• Plugin methods declare their inputs through plain Python type hints. Ocelescope reads those hints to auto-generate the input form in the UI, so you never write frontend code.

Before you start

• You should be comfortable writing Python; a plugin is just a Python package.
• It helps to know the core types from the ocelescope package: OCEL (the event log) and Resource (the artifacts methods consume and produce). Resources covers the latter in depth.
• Walking through Explore the Basics first gives you the user’s-eye view, how logs, resources, and filters behave, which is the side your plugin will plug into.

How this section is organized

• Plugin Structure: how a plugin package is laid out, and how one archive can bundle several plugin modules.
• Plugin Class: the single Plugin subclass per module, its metadata, and how @plugin_method turns a function into a runnable method with an auto-generated form.
• Plugin Environment: which packages are available at runtime, and how to bundle or request more.
• Build and Package: turning your project into the .zip Ocelescope expects, and submitting it to the plugin library.
• Tutorial: Plugin Development: a guided, end-to-end walkthrough that builds a real plugin from scratch.

Related concepts

• Resources: read this when you’re defining a new resource type for a method’s input or output, or want to give it a custom visualization.
• Extensions: read this when your plugin needs custom data to travel with the OCEL file itself on import/export, rather than living in a separate resource.
• Request additional package: ask for a PyPI package to be added to the shared plugin environment.

Get started!

The next pages give you all the info you need to get started with your own plugin. However, if you’re more of a visual person, this video shows how a plugin is developed from existing, published research code not associated with the project. It explains the plugin structure and how it is represented in the code, and walks through the different steps of plugin development.

If you’d rather dive straight in yourself, start with the Tutorial or fork the minimal plugin template referenced in Plugin Structure.

Submit a Plugin Once your plugin is ready and published as a GitHub release, add it to the public Ocelescope plugin library.
